Bently Nevada 3300 XL Proximity Probe: Heavy-Duty Vibration Monitoring
Industrial-grade 11mm sensor with 5/8-18 UNF thread for critical machinery protection. Features triaxial cable and multiple certifications.
Core Specifications
| Brand | Bently Nevada |
| Model | 330708-00-24-50-01-05 |
| Thread Size | 5/8-18 UNF |
| Case Length | 2.4 inches |
| Cable | 5.0 meters triaxial |
| Temperature | -51°C to +177°C |
Suffix Details
- 00: 0in unthreaded length
- 24: 2.4in case length
- 50: 5.0 meter cable
- 01: ClickLoc connector with protector
- 05: Multiple agency approvals
Technical Specifications
- Probe Type: 11mm proximity
- Cable Type: 75Ω triaxial FEP
- Resistance: 7.2Ω ±0.8
- Case Material: AISI 304 stainless steel
- Tip Material: Polyphenylene sulfide (PPS)
- Weight: 0.17kg
- Bend Radius: 25.4mm minimum
Installation Guide
- Max thread engagement: 0.938 inch
- Recommended torque: 133 in-lb
- Max torque: 400 in-lb
- Seal: Viton O-ring (avoid below -34°C)
- For use with 5m Proximitor Sensor only
Certifications
Multiple international approvals (Option 05 suffix). COO (Certificate of Origin) available.
Package Contents
- 1x Proximity probe
- Connector protector
- 12-month manufacturer warranty
Global Shipping
Fast delivery via FedEx, UPS, DHL
FAQ
Q: What does triaxial cable mean?
A: Three-layer shielded cable for better signal quality.
Q: Minimum installation temperature?
A: Avoid below -34°C to prevent seal damage.
Q: Pressure testing available?
A: Contact custom design department for special requests.
Q: Compatible with other sensors?
A: Works only with 5m Proximitor Sensors.
Q: Lead time for orders?
A: Ships same day from US stock.
