Description
Core Features for 330101-00-19-10-01-CN
- ???? 1.9in Extended Case (Code 19)
- ???? 1m ClickLoc® Cable (Code 10)
- ???? China GB Standards (Code CN)
- ???? 7.59Ω ±0.5 at 1m
Full Model Code for 330101-00-19-10-01-CN
| Code | Specification |
|---|---|
| 00 | 0.0in Unthreaded |
| 19 | 1.9in Case Length |
| 10 | 1.0m Cable |
| 01 | ClickLoc Connector + Protector |
| CN | China Approvals |
Technical Data
| Parameter | Value |
|---|---|
| Linear Range | 2mm (80 mils) |
| Scale Factor | 7.87 V/mm ±5% |
| Temp Range | -52°C to +260°C |
| Cable Strength | 330N (75 lbf) Pull Resistance |
| Humidity Resistance | <3% ASF change @93% RH |
Installation Guide
- ⚙️ Max Wiring: 305m (1,000ft)
- ⚙️ Optimal Gap: -9 Vdc (1.27mm)
- ⚙️ Use Shielded Triad Cable
Certifications
- ✅ China GB/T 18663-2010
- ✅ ATEX/IECEx Ex nA IIC T4
- ✅ RoHS & IEC 61207-1
Industry Application
Monitors automotive paint drying ovens detecting conveyor chain vibrations in 200°C high-humidity environments.
Package Contents
- ???? 1x Probe (1.9in case)
- ???? Connector Protector
- ???? 1-Year Warranty
Contact Support
???? sales@ubestplc.com
