Description
Product Overview
The Bently Nevada 330104-10-16-10-12-00 is a water-resistant 8 mm proximity probe built for industrial automation. Features 10 mm unthreaded section, 16 mm case, and FluidLoc™ cable for wet environments. Includes Viton® O-rings and stainless steel housing.
Key Specifications
- Brand: Bently Nevada
- Model: 3300 XL 8 mm Proximity Probe
- Full Suffix: 330104-10-16-10-12-00
- Thread: M10 x 1
- Unthreaded Length: 10 mm
- Case Length: 16 mm
- Cable: 1.0 m FluidLoc™ (IP67 rated)
- Resistance: 7.59 Ω ±0.50
- Voltage Range: -17.5 Vdc to -26 Vdc
- Temp Range: -55°C to +232°C (T1 class)
Installation Guide
- Mount with 10 mm unthreaded area exposed.
- Keep 1.27 mm gap from AISI 4140 steel targets.
- Use -24 Vdc power for best performance.
Package Includes
- 8 mm Proximity Probe
- 1.0 m FluidLoc™ Cable
- ClickLoc Connector
- Viton® Sealing Kit
Warranty
12-month defect-free warranty.
Industrial Applications
- Dairy processing mixer vibration control
- Wind turbine gearbox monitoring
- Beverage canning line motor alignment
