330173-00-06-10-12-00 Bently Nevada 3300 5mm Probe Proximity Probes

Description

Bently Nevada 330173-00-06-10-12-00 – 5mm Industrial Vibration Probe

⚡ Key Specifications

• ???? Dimensions: 60mm case | 1.0m FluidLoc® cable
• ????️ Temp Range: -35°C to +177°C (Avoid < -34°C)
• ???? Connector: ClickLoc with gold-plated contacts
• ⚙️ Resistance: 7.59Ω ±0.50 (center to outer conductor)

???? Model Code Breakdown

330173-00-06-10-12-00
├─ 00: No unthreaded length
├─ 06: 60mm case length
├─ 10: 1.0m cable
├─ 12: ClickLoc connector
└─ 00: No agency approvals

???? Industrial Applications

• ????️ Oil & Gas: Compressor bearing monitoring in API 670 systems
• ⚡ Power Generation: Steam turbine shaft vibration analysis
• ???? Manufacturing: CNC machine tool spindle monitoring

⚠️ Critical Notes

• ???? Max torque: 7.3 N·m (65 in·lb)
• ???? Minimum bend radius: 25.4mm (1.0in)
• ???? COO available upon request
