Description
Bently Nevada Probe 330191-00-08-10-CN
New 330191-00-08-10-CN | 12-Month Warranty | Country-Specific Certified
Part Code Breakdown
| Suffix Details | 00 = 0.0″ Unthreaded 08 = 0.8″ Case 10 = 1.0m Cable (3.3 ft) CN = Country-Specific Approval |
Key Specifications
- Voltage: -17.5V to -26V DC
- Resistance: 7.59Ω ±0.50
- Max Current: 12mA
- Pull Strength: 75 lbs
- Weight: 11.4 oz/ft
- Temp Range: -55°C to +80°C
Design Highlights
- 8mm Thick PPS Plastic Tip
- Stainless Steel Body (303/304)
- Viton® O-Ring Seal
- Gold-Plated Brass Connectors
Industry Applications
| Electronics Assembly Lines | Small Pump Systems |
| Precision Tooling Machines | HVAC Fan Monitoring |
Installation Notes
- Use with 1m Proximitor Only
- Max Torque: 5 in-lb
- Follow Diagram 140979
Support: sales@ubestplc.com
Explore more detailed information in official datasheet here: 3300 XL 8 mm Proximity Transducer System Datasheet
