330701-00-10-90-02-00 Bently Nevada 3300 XL 11 mm Probe

Description

Bently Nevada 9m Proximity Probe: Long-Reach Machinery Monitoring

Extra-long 9-meter sensor for hard-to-reach equipment. Features Viton temperature seals and chemical-resistant cable. Made in USA.

Technical Specifications

• Product ID: 330701-00-10-90-02-00
  • 00: 0″ unthreaded section
  • 10: 1.0″ case length
  • 90: 9m cable (29.5 ft)
  • 02: ClickLoc connector
  • 00: No approvals needed
• Electrical:
  • Resistance: 8.5Ω ±1.1
  • Cable: 75Ω triaxial FEP
• Physical:
  • Thread: 1/2-20 UNF
  • Min bend: 25.4mm (1″)
  • Weight: 0.17kg
• Environment:
  • Temp range: -51°C to +177°C
  • Seal: Viton O-ring

Installation Notes

• Max torque: 15.2 N•m (133 in•lb)
• Connectors: Finger tight + max 0.565 N•m
• Keep above -34°C to protect seals

Shipping & Support

• Warranty: 12 months
• Shipping: FedEx • UPS • DHL
• COO: Available on request

Probe FAQ

• Q: Can this 9m probe monitor underwater equipment?
  A: Yes – FEP cable resists water and chemicals
• Q: What’s the maximum vibration frequency it detects?
  A: Up to 12 kHz for precise measurements
• Q: Is calibration required before installation?
  A: Pre-calibrated – ready for immediate use
• Q: Can I repair damaged cables?
  A: No – replace entire probe if cable fails
• Q: How close should probes be to rotating shafts?
  A: 1.0-2.5mm gap recommended
