Description
Bently Nevada 3300 XL 11mm Proximity Probe: Precision Vibration Monitoring
Product Code Breakdown: 330702-00-10-50-11-00
- 00 → 0″ unthreaded length
- 10 → 1.0″ case length
- 50 → 5.0 meter cable (16.4 ft)
- 11 → Mini ClickLoc + FluidLoc
- 00 → No agency approvals
Key Technical Specs
- Thread: ½-20 UNF with armor
- Resistance: 7.2Ω ±0.8 (center to outer conductor)
- Temp Range: -51°C to +177°C
- Cable: 75Ω triaxial FEP (5m fixed length)
- Torque: Max 45.2 N•m | Recommended 15.2 N•m
- Bend Radius: 25.4mm (1.0″) minimum
- Weight: 0.17 kg
Installation Notes
- ⚠️ For 5m Proximitor Sensors only
- ???? Max thread engagement: 0.750″ (½-20)
- ⚡ Match total probe + extension length
- ❄️ Avoid below -34°C to protect seals
Support & Shipping
- 12-month warranty
- Global delivery: FedEx, UPS, DHL
- Made in USA quality
Technical FAQs
- Q: Can I use 9m cable instead?
A: No – 5m probes work only with 5m systems - Q: Pressure seal rating?
A: Contact us for custom pressure testing - Q: Thread adapters available?
A: Yes for M16x1.5 or 5⁄8-18 - Q: Replaceable tip?
A: No – PPS tip is permanently bonded - Q: Lead time for non-armored?
A: 3-5 business days
