Description
Bently Nevada 3300 XL 11mm Sensing Probe
Product Summary
330707-00-10-10-01-00 | Made in USA | COO available
Complete Model Number Meaning
- 330707: 11mm probe body
- 00: No unthreaded section
- 10: 1.0 inch case length
- 10: 1.0 meter cable
- 01: ClickLoc connector + standard cable
- 00: No agency approvals
Essential Specifications
- Brand: Bently Nevada
- Sensing Range: 11mm diameter
- Tip Material: PPS plastic
- Case: Stainless steel
- Cable: Triaxial standard (1m/5m/9m)
- Temperature: -51°C to +177°C
- Resistance: 5.9Ω ±0.5Ω
Installation Parameters
- Max Torque: 45.2 N•m (400 in•lb)
- Safe Torque: 15.2 N•m (133 in•lb)
- Min Bend Radius: 25.4mm
- Max Thread: 0.938 inch engagement
- Connector Torque: 0.565 N•m max
Environmental Warnings
- Seal Type: Viton O-ring
- Critical: Avoid below -34°C
- Pressure Test: Not included
- Storage Limits: Same as operating
Shipping Information
Package Weight: 0.17 kg
Delivery: FedEx · UPS · DHL
Condition: Factory sealed new
Technical FAQ
- Q: Approval certifications included?
A: No – option 00 means no approvals - Q: Cable protection type?
A: Standard (non-FluidLoc) version - Q: Minimum thread engagement?
A: No minimum specified - Q: High-temperature limit?
A: +177°C continuous operation - Q: Conductor resistance tolerance?
A: ±0.5Ω at 20°C ambient
