Description
Bently Nevada 3300 XL 11mm Proximity Probe
Product Overview
New 330707-00-10-10-02-05 probe made in USA. Includes 12-month warranty. Optional Certificate of Origin (COO) available.
Full Model Suffix Details
- 330707: 3300 XL 11mm Probe
- 00: 0″ unthreaded length
- 10: 1.0″ case length
- 10: 1.0 meter cable
- 02: ClickLoc connector
- 05: Multiple agency approvals
Key Specifications
- Brand: Bently Nevada
- Thread: 5/8-18 UNF
- Probe Tip: PPS material
- Case: Stainless steel
- Resistance: 5.9Ω ±0.5Ω
- Temperature: -51°C to +177°C
- Cable: 75Ω triaxial, 1.0m FEP
Installation Notes
Max Torque: 45.2 N•m (400 in•lb)
Recommended Torque: 15.2 N•m (133 in•lb)
Min Bend Radius: 25.4mm (1.0 in)
Thread Engagement: 0.938″ max
Pressure & Handling
Sealed with Viton O-ring. Not pressure tested before shipping. Contact for custom pressure tests. Avoid temperatures below -34°C to protect seal.
Shipping & Packaging
Weight: 0.17 kg
Carriers: FedEx, UPS, DHL
Includes: Factory packaging
Expert FAQ
- Q: Minimum installation temperature?
A: Avoid below -34°C to prevent seal damage - Q: Cable length options available?
A: 1m, 5m or 9m total lengths - Q: Triaxial cable benefits?
A: Better noise resistance in industrial environments - Q: Thread engagement limit?
A: Maximum 0.938 inch for 5/8-18 thread - Q: Chemical resistance rating?
A: PPS tip resists most industrial chemicals
