Description
Description:
The Allen-Bradley 1794-IE8 is a high-quality analog input module designed for flexible integration into industrial automation systems. This module supports both voltage and current input types, offering versatile signal interface options. The 1794-IE8 is engineered to handle a variety of analog signals and provides 8 input channels, all of which are suitable for different types of control systems, making it an ideal choice for applications requiring precise signal processing. With a rugged design, it ensures reliable performance even in harsh operating environments.
Technical Data:
| Specification | Details |
|---|---|
| Brand | Allen-Bradley |
| Model | 1794-IE8 |
| Component Type | Fieldbus I/O |
| Number of Analog Inputs | 8 qty |
| Analog Input Types | Current / Voltage (Single-Ended) |
| Analog Input Ranges | -10 to +10V DC 0 to 10V DC 0 to 20mA 4 to 20mA |
| Analog Resolution (Input) | 12-bit (unsigned / unipolar) |
| Power Supply | 24V DC |
| Module Specific Functions | Interfaces analog signals with any programmable controller with block transfer capability |
| Operating Temperature Range | Max: 55°C Min: 0°C |
| Weight | Approx. 0.23 kg (0.51 lbs) |
