Description
Bently Nevada 3300 XL Vibration Sensor: Reliable Machine Monitoring
Essential Features
Precision 11mm proximity probe for industrial equipment. Made in USA with chemical-resistant PPS tip and stainless steel body. Works in extreme temperatures from -51°C to +177°C. Includes protective connector cover.
Complete Product Details
| Full Product Code | 330708-00-10-50-01-00 |
| Sensor Size | 11mm diameter |
| Cable Length | 5.0 meters / 16.4 ft |
| Electrical Resistance | 5.9 ± 0.5 ohms |
| Thread Type | 5/8-18 UNF |
| Connector | ClickLoc with protector |
| Max Bend Radius | 25.4mm (1 inch) |
What’s In Your Order
- Vibration probe with 5m cable
- ClickLoc connector with protector
Technical Specifications
- Thread engagement: Max 0.938 inch
- Cable type: 75 Ω triaxial FEP
- Case torque: 15.2 N•m recommended (45.2 N•m max)
- Connector torque: Finger tight + max 0.565 N•m
- Shipping weight: 0.17 kg
Installation Notes
- Seal material: Viton O-ring
- Avoid temperatures below -34°C to protect seal
- Not pressure tested – contact for special tests
Shipping & Support
12-month product warranty. Ships via FedEx/UPS/DHL. Delivery worldwide.
Common Questions
Q: What does “00” mean in product code?
A: First “00” = no unthreaded section. Last “00” = no special approvals.
Q: Cable length options?
A: Available in 1m, 5m (this model), or 9m lengths.
Q: Thread compatibility?
A: Works with M14x1.5 (21mm), M16x1.5 (24mm), and 5/8-18 UNF systems.
Get Full Instructions
Download complete installation manual for this probe. Click here for technical documents.
