Bently Nevada 3300 XL 11mm Probe – Industrial Vibration Sensor
U.S.-made precision probe for machinery monitoring. Features 5m cable and PPS tip. Download installation guide at bottom.
Complete Product Identification
- Base model: 330708 (11mm probe)
- Unthreaded length: 00 (0 inch)
- Case length: 10 (1.0 inch)
- Cable length: 50 (5.0 meters)
- Connector: 02 (ClickLoc)
- Approvals: 00 (Standard)
Core Specifications
- Sensing range: 11mm
- Cable length: 5m (16.4 ft)
- Temp range: -51°C to +177°C
- Resistance: 5.9Ω ±0.5Ω
- Cable type: 75Ω triaxial
Physical Details
| Thread type | 5/8-18 UNF |
| Max thread depth | 0.938 in |
| Case material | AISI 304 stainless steel |
| Tip material | PPS plastic |
| Bend radius | 25.4mm min |
Installation Notes
- Recommended torque: 15.2 N·m
- Max torque: 45.2 N·m
- Connectors: Finger tight only
- Seal material: Viton O-ring
Compatibility & Use
- Works with Bently Nevada 3300/3500 systems
- Perfect for pumps and motors
- Industrial compressor monitoring
- Power generation equipment
What’s Included
- 1 vibration probe
- COO available on request
- Shipping weight: 0.17kg
Support & Services
- 12-month warranty
- Global shipping: FedEx/UPS/DHL
- Pressure testing available (contact us)
Technical Questions
Q: What’s the cable material?
A: FEP-insulated triaxial cable
Q: Can I use this in cold environments?
A: Yes, but avoid below -34°C to protect seals
Q: Is this explosion-proof?
A: No special approvals (option 00)
Q: What’s the thread size?
A: 5/8-18 UNF standard
Get the Full Manual
Download complete installation guide:
3300 XL 11 mm Proximity Transducer System Datasheet
Need help? Contact our technical team for setup advice.
