Description
Bently Nevada 3300 XL Industrial Sensor: Long-Reach Vibration Monitoring
Core Advantages
9-meter range vibration sensor for hard-to-reach machinery. Features connector protector and chemical-resistant PPS tip. Works from -51°C to +177°C. Made in USA with stainless steel body.
Product Identification
| Complete Model | 330708-00-10-90-01-00 |
| Base Number | 330708 (11mm probe) |
| First Suffix: 00 | No unthreaded section |
| Second Suffix: 10 | 1.0 inch case length |
| Third Suffix: 90 | 9 meter cable |
| Fourth Suffix: 01 | ClickLoc connector with protector |
| Fifth Suffix: 00 | No special approvals |
Performance Details
- Cable resistance: 5.9 Ω ±0.5 at 1m
- Max thread depth: 0.938 inch (23.8mm)
- Seal material: Viton O-ring
- Min bend radius: 25.4mm (1 inch)
- Weight: 0.17 kg
Installation Guide
- Use 15.2 N•m torque for case
- Hand-tighten connectors only
- Keep above -34°C during installation
- Check O-ring before use
Package Contents
- 9m sensor with protected connector
- Mounting instructions
- Optional COO certificate
Shipping & Protection
12-month quality guarantee. Ships worldwide via FedEx/UPS/DHL. Tracking provided.
Important Answers
Q: Can I cut the cable shorter?
A: No – cutting changes electrical properties.
Q: Is this waterproof?
A: Sealed against moisture but not pressure-rated.
Q: Thread compatibility?
A: Fits 5/8-18 UNF, M14x1.5, and M16x1.5 ports.
Need More Details?
Download full technical manual for installation diagrams and specifications.
