Description
Bently Nevada FluidLoc Proximity Probe – 9m Industrial Sensor
High-performance 11mm vibration monitor with specialized FluidLoc cable. Made in USA for demanding environments.
Product Identification
- Full Model: 330708-00-10-90-11-00
- Series: 3300 XL 11mm Probes
- Origin: U.S.A. manufactured
Configuration Breakdown
- 330708 – Base probe type
- 00 – No unthreaded section
- 10 – 1.0 inch case length
- 90 – 9.0 meter cable length
- 11 – FluidLoc cable with ClickLoc
- 00 – No agency approvals
Technical Parameters
- Cable Resistance: 5.9Ω ±0.5 per meter
- Seal Material: Viton O-ring
- Minimum Temp: -34°C operational limit
- Max Temp: +177°C continuous
- Cable Type: FEP-insulated triaxial
- Thread Spec: 5/8-18 UNF
Installation Specifications
- Optimal Torque: 15.2 N•m
- Max Torque: 45.2 N•m
- Bend Radius: 25.4mm minimum
- Thread Engagement: 0.938 inch max
Shipping & Support
- Package Weight: 0.17 kg
- 12-month coverage
- Delivery Options: FedEx, UPS, DHL
- Origin certificate available
Frequently Asked Questions
- Q: FluidLoc vs standard cable?
A: FluidLoc has better fluid resistance - Q: Approval differences for option 00?
A: No certifications included - Q: Cable replacement possible?
A: Not recommended – sealed unit - Q: Saltwater compatibility?
A: Yes – stainless steel and FEP materials - Q: Vibration measurement range?
A: Contact for application-specific specs
Documentation Download: 3300 XL 11 mm Proximity Transducer System Datasheet
Access installation guides and technical manuals. Email our support team for complete documentation package.
