Description
Bently Nevada 3300 XL 11mm Proximity Probe
What You Get
- New 330708-00-24-90-01-00 probe with 9 meter cable
- Made in USA with 12-month warranty
- Factory sealed packaging
Part Number Details
- 330708: 11mm Probe body
- 00: 0 inch unthreaded section
- 24: 2.4 inch case length
- 90: 9 meter cable
- 01: ClickLoc connector
- 00: No agency approval needed
Key Specifications
- Cable Length: 9 meters (29.5 feet)
- Thread Type: 5/8-18 UNF
- Temperature Range: -51°C to +177°C
- Probe Resistance: 8.5Ω ±1.1Ω
- Cable Type: 75Ω triaxial FEP
- Weight: 0.17 kg
Installation Guide
- Max Thread Depth: 0.938 inches
- Install Torque: 15.2 N•m
- Max Torque: 45.2 N•m
- Bend Radius: Keep >25.4mm
- Min Temp Warning: Do not install below -34°C
Pressure Seal
Viton O-ring seals pressure differences. Not tested before shipping. Contact us for pressure testing services.
Cable Options
- Works with 1m, 5m or 9m cables
- Miniature ClickLoc connector
- Standard FEP cable
Shipping Info
Ships worldwide via FedEx, UPS or DHL. Delivery in 3-5 business days.
Water Treatment Plant Use
Monitors pump bearings in wet environments. Resists corrosion at high humidity. Works at temperatures from 5°C to 60°C.
Common Questions
Q: What thread size is this probe?
A: 5/8-18 UNF thread
Q: Minimum safe temperature?
A: Do not use below -34°C
Q: Cable replacement options?
A: Use 75Ω triaxial FEP cables only
Q: Warranty period?
A: 12 months from purchase date
Get Full Manual
Download installation guide: Click Here for Probe Manual PDF
