Description
330902-00-50-05-02-05Multi-Certified 3300 NSv Short-Body Proximity Sensor
???? Dimensional Mastery:
• Case: 5″ (127mm) AISI304 SST with 9.53mm max thread engagement
• Cable: 0.5m FEP 75Ω (±4.0Ω @20°C)
• Profile: 14-150g weight | 20″ total length
• Case: 5″ (127mm) AISI304 SST with 9.53mm max thread engagement
• Cable: 0.5m FEP 75Ω (±4.0Ω @20°C)
• Profile: 14-150g weight | 20″ total length
????️ Certification Cluster:
| ATEX II 1G | IECEx EPL Ga |
| NEPSI Ex ia IIC T4 | ISO 80079-36:2016 |
???? Performance Matrix:
- ▶️ 45 in-lb installation torque (65 max)
- ▶️ -52°C cold start capability
- ▶️ 72hr thermal cycling tested
- ▶️ 5kV ESD surge protection
???? Premium Features:
⦿ 1-year explosion-proof warranty
⦿ 50MΩ insulation resistance (500VDC)
⦿ IP66 ingress protection (operational)
⦿ Chemical-resistant PPS tip (UL94 V-0 rated)
⚠️ Installation Alert:
Avoid continuous exposure below -30°F/-34°C. Max 3.2 bar pressure differential. Requires 0.25-0.35Nm anti-seize lubricant during threading.
