Bently Nevada 330903-00-02-50-01-00: Precision Vibration Sensor
New M8X1 thread probe with 5-meter cable for machine health monitoring. Made in USA with 12-month warranty.
PRODUCT CODE EXPLAINED
- 330903 – Base model (M8X1)
- 00 – 0mm unthreaded section
- 02 – 20mm case length
- 50 – 5.0 meter cable
- 01 – Standard ClickLoc connector
- 00 – No agency approvals
TECHNICAL PARAMETERS
- Cable Resistance: 5.3 Ω ±0.7
- Frequency Range: 0-10,000 Hz
- Target Size: Min 8.9mm (0.35″) diameter
- Scale Factor: 7.87 V/mm ±20%
- Bend Radius: 25.4mm (1.0″) minimum
- Wire Gauge: 0.2-1.5 mm² (16-24 AWG)
- Capacitance: 69.9 pF/m typical
INSTALLATION SPECS
- Best Gap: 1.0mm from target
- Max Torque: 7.3 N•m (65 in•lb)
- Thread Limit: 12mm engagement max
- Seal Type: Viton O-ring
- Temp Limits: -52°C to +177°C
COMPATIBILITY
Fits all Bently Nevada 3300 systems. Compatible with older 3300 RAM probes.
PACKAGE CONTENTS
- New probe in factory packaging
- 12-month manufacturer warranty
SHIPPING DETAILS
- Global delivery via FedEx, UPS, DHL
- Tracking provided with all orders
OPERATIONAL FAQ
- Q: What is the cable length?
A: 5.0 meters (16.4 feet) - Q: Minimum shaft size for accuracy?
A: 13mm recommended, 8.9mm minimum - Q: How to improve readings on small shafts?
A: Reduce gap between probe and target - Q: Max wiring distance to monitor?
A: 305 meters (1000 feet) - Q: What is FluidLoc cable?
A: Not included in this model (option 01 = standard) - Q: Warranty coverage period?
A> Full 12 months from purchase date
