Description
Bentley Nevada 3300 NSv Compact FluidLoc Probe
Short-case vibration sensor with FluidLoc cable protection. Ideal for tight spaces in industrial machinery.
PRODUCT CONFIGURATION
| Part Number Segment | Meaning | Value |
| 330903 | Base Model | M8x1 thread, no armor |
| 00 | Unthreaded Length | 0 mm |
| 02 | Case Length | 20 mm |
| 50 | Cable Length | 5.0 meters |
| 11 | Connector | ClickLoc with protector + FluidLoc |
| 00 | Approvals | None required |
KEY PERFORMANCE DATA
- Electrical Resistance: 5.3Ω ±0.7Ω
- Measurement Range: 1.5 mm (60 mils)
- Accuracy Error: Less than ±0.06 mm
- Response Frequency: 0-10,000 Hz
- Cable Bend Radius: 25.4 mm minimum
MECHANICAL SPECIFICATIONS
- Case Material: AISI 304 stainless steel
- Tip Material: Chemical-resistant PPS
- Seal Type: Viton O-ring
- Max Torque: 7.3 N•m
- Recommended Torque: 5.1 N•m
ENVIRONMENTAL RATINGS
- Operating Temp: -52°C to +177°C
- Storage Temp: -52°C to +177°C
- Min Target Size: 8.9 mm diameter
INSTALLATION GUIDE
- Mount with max 5.1 N•m torque
- Set gap at 1.0 mm (40 mils)
- Use shielded triad cable for field wiring
- Maintain min bend radius: 25.4 mm
PACKAGE CONTENTS
- 3300 NSv Probe with 5m FluidLoc cable
- Mini ClickLoc connector with protector
- Original factory packaging
WARRANTY & SHIPPING
12-month manufacturer warranty against defects. Ships worldwide via:
FedEx | UPS | DHL – Tracking included
TECHNICAL FAQ
Q: Why choose 20mm case length?
A: Perfect for confined spaces where standard probes won’t fit
Q: FluidLoc vs standard cable?
A: Better resistance to oils and chemicals
Q: How accurate is vibration measurement?
A: ±0.06 mm precision across full temperature range
Q: Minimum target size?
A: 8.9 mm diameter (13mm recommended)
Q: Response time for sudden vibration?
A: Captures events up to 10,000 times per second
