330903-00-02-70-01-05 Bently Nevada 3300 NSv Proximity Probes

Description

Bently Nevada 3300 NSv Compact Proximity Sensor

Precision Vibration Detection

New 330903-00-02-70-01-05 probe features 20mm compact case and standard cable. With M8X1 threading and multiple certifications. Includes 12-month warranty.

Part Number Guide

• Full Code: 330903-00-02-70-01-05
• Configuration:
  • -00-: Zero unthreaded section
  • -02-: 20mm short body
  • -70-: 7.0 meter cable
  • -01-: Standard cable
  • -05: Multi-certified

Key Measurements

• Electrical resistance: 5.9Ω ±0.9
• Cable type: 75Ω coaxial FEP
• Frequency range: 0-10kHz (±3dB)
• Thread depth: 12mm maximum
• Compact 20mm design

Performance Features

• Voltage output: -1V to -13V
• Accuracy: ±0.06mm deviation
• PPS tip material
• Stainless steel 304 housing
• Chemical-resistant design

Mounting Guide

• Target distance: 1.0mm optimal
• Installation torque: Finger tight
• Minimum target: 13mm diameter
• Cable bend: 1.0 inch radius

Certifications & Package

• Multiple global approvals
• Original factory packaging
• Connector protector included
• Full documentation

Global Shipping

Fast delivery via FedEx, UPS, DHL. Tracking provided.

FAQs

Q: What case length is this model?
A: Compact 20mm body (suffix -02-)

Q: Cable type difference?
A: Standard cable (not FluidLoc)

Q: Where use short case probes?
A: Space-limited installations

Q: Included certifications?
A: Multiple international approvals
