Bently Nevada 3300 NSv Proximity Probe – Premium Precision for Industrial Monitoring
Description
Brand new original probe with full factory warranty. Designed for precision vibration measurement, this M8X1 threaded probe features enhanced chemical resistance and superior side-view characteristics compared to older models. Ideal for process compressors and critical rotating machinery.
Technical Specifications
Brand: Bently Nevada
Model: 330903-00-04-70-12-05
Linear Range: 1.5 mm (60 mils)
Accuracy: ±0.06 mm deviation
Output Signal: -1 to -13 Vdc
Scale Factor: 7.87 V/mm
Temp Range: -52°C to +177°C
Probe Resistance: 5.9Ω ±0.9Ω
Cable Type: FluidLoc FEP coaxial
Installation Guide
- Gap Setting: 1.0 mm (40 mils) recommended
- Torque: 5.1 N•m (45 in•lb) max
- Min Target: Ø13mm flat surface
- Bend Radius: >25.4mm (1.0in)
- Field Wiring: 3-conductor shielded triad
Compatibility
Direct replacement for 3300 RAM probes. Electrically and mechanically compatible with existing Bently Nevada monitoring systems. Superior performance to 3000-series 190 probes.
Certifications
Multiple agency approvals (Option 05). Sealed with Viton O-ring for pressure environments.
Package Includes
- 330903-00-04-70-12-05 Probe unit
- Factory documentation
- Original protective packaging
Warranty & Shipping
12-month warranty. Ships worldwide via FedEx, UPS, or DHL. Delivery within 3-5 business days.
FAQ
Q: Is armor included?
A: No, this version (-00) has no armor.
Q: Minimum shaft size?
A: 13mm diameter recommended
Q: Pressure rating?
A: Contact for custom pressure testing
