330903-00-04-70-01-05 Bently Nevada Proximity Probe No Armor

Description

Bently Nevada 3300 NSv Proximity Probe – Premium Vibration Sensing Solution

Product Description

New original Bently Nevada 330903-00-04-70-01-05 proximity probe in factory packaging. Features enhanced chemical resistance for harsh environments and superior side-view performance vs older probes. Fully compatible with 3300 RAM systems. Includes 12-month manufacturer warranty.

Technical Specifications

Brand: Bently Nevada

Model: 3300 NSv Probe (Full suffix: 330903-00-04-70-01-05)

Key Parameters:

• Range: 1.5mm (60 mils)
• Accuracy: < ±0.06mm DSL
• Output: 7.87 V/mm (±12.5%)
• Temp Range: -52°C to +177°C
• Resistance: 5.9Ω ±0.9
• Cable: 7.0m FEP coaxial
• Thread: M8X1 (no armor)

Installation Guide

Torque Settings:

• Recommended: 5.1 N•m (45 in•lb)
• Maximum: 7.3 N•m (65 in•lb)

Bend Radius: > 25.4mm (1.0 in)
Thread Engagement: 12mm max
Gap Setting: 1.0mm (40 mils) optimal

Compatibility

Electrically and mechanically compatible with:
• 3300 RAM proximity systems
• 3300 XL NSv Proximitor Sensors
Uses standard 75Ω coaxial cabling

Certifications

Multiple international approvals (Option 05)
Viton O-ring pressure seal

Packaging & Warranty

•  Factory-sealed original packaging
• 12-month warranty
• Shipping: FedEx, UPS, DHL worldwide

FAQ

Q: Minimum target size?
A: 8.9mm diameter (13mm recommended)

Q: Cable length options?
A: Standard lengths: 0.5m, 1m, 5m, 7m

Q: Pressure testing?
A: Not tested pre-shipment (contact for custom testing)
