Bently Nevada 330903-00-05-70-11-05 Proximity Probe No Armor

Description

Bently Nevada 3300 NSv Proximity Probe with FluidLoc Technology

Advanced Machinery Protection

New 330903-00-05-70-11-05 sensor combines 50mm case length and FluidLoc cable. Features M8X1 threading and multi-certifications. Includes 12-month factory warranty for industrial reliability.

Part Number Breakdown

• Full Identification: 330903-00-05-70-11-05
• Suffix Details:
  • Position 1-2: -00- = 0mm unthreaded
  • Position 3-4: -05- = 50mm body
  • Position 5-6: -70- = 7m cable
  • Position 7-8: -11- = FluidLoc cable
  • Position 9-10: -05 = Multi-certified

Essential Specifications

• Electrical: 5.9Ω probe resistance
• Response: 10kHz frequency range
• Material: PPS tip + 304 stainless steel
• Cable: 75Ω FEP coaxial
• Output: -1V to -13V linear range

Unique Features

• Enhanced chemical-resistant FluidLoc cable
• Viton O-ring pressure sealing
• 0.56 N•m maximum torque
• 1-inch minimum bend radius
• Extended 50mm housing

Installation Tips

• Set gap: 1.0mm from target surface
• Hand-tighten only (no tools needed)
• Maintain 25mm cable bend minimum
• Use 13mm+ target diameter

Compliance & Packaging

• Multiple global certifications
• Factory-sealed protective packaging
• ClickLoc connector with protector
• 12-month manufacturer coverage

Shipping Options

Fast global delivery via FedEx, UPS, DHL. Tracking provided.

FAQs

Q: What does FluidLoc mean?
A: Special cable for chemical resistance

Q: When use 50mm case?
A: For deep mounting locations

Q: Difference between -11- and -02-?
A: -11- has FluidLoc, -02- standard cable

Q: Pressure rating?
A: Contact for custom testing service
