Description
Bently Nevada 3300 NSv Proximity Sensor
Essential Machine Health Monitoring
Brand-new 330903-00-03-70-01-05 proximity probe with full factory warranty. Designed with 30mm case length and 7.0m standard cable. Upgrade solution for existing 3300 RAM systems offering better chemical resistance.
Complete Product Details
| Brand | Bently Nevada |
| Full Model Code | 330903-00-03-70-01-05 |
| Thread Type | M8x1 |
| Case Length | 30 mm |
| Cable Length | 7.0 meters |
| Connector Type | ClickLoc with protector |
| Approvals | Multiple global |
Key Performance Data
- Measuring Range: 1.5 mm (0.06 inches)
- Accuracy: ±0.06 mm deviation
- Sensitivity: 7.87 V/mm (±12.5%/-20%)
- Temp Limits: -52°C to +177°C
- Cable Type: Standard 75Ω coaxial
- Resistance: 5.9Ω ±0.9Ω
- Response: 0-10 kHz (±3dB)
Easy Installation
- Mounting Torque: Finger tight only
- Best Gap: 1.0 mm from target
- Min Shaft Size: 13 mm diameter
- Cable Bend: >25.4 mm radius
- Thread Use: Max 12 mm depth
Compatibility Note
Works with all 3300 RAM system components. Better chemical protection than older probes.
Safety Approvals
Meets multiple international standards (Option 05).
What You Receive
- Factory-sealed probe with protector cap
- 12-month warranty
- FedEx/UPS/DHL fast shipping options
Common Questions
Q: Cable protector included?
A: Yes, connector protector included
Q: Pressure rating?
A: Viton sealed (test available on request)
Q: Different from 3300 RAM?
A: Better chemical and heat resistance
