Description
Bently Nevada 3300 NSv Probe with Connector Protector
Product Overview
Brand new 330903-00-05-70-01-05 proximity probe. Features connector protector for extra safety. Comes in original packaging with 12-month factory warranty.
Complete Model Breakdown
- Brand: Bently Nevada
- Base Model: 3300 NSv
- Full Code: 330903-00-05-70-01-05
- Thread: M8X1 (no armor)
- Case Size: 50mm length
- Cable: 7.0m standard
- Connector: ClickLoc with protector
- Approvals: Multiple (Option 05)
Key Specifications
- Measuring Range: 1.5mm (0.25-1.75mm linear)
- Accuracy Error: < ±0.06mm
- Output Signal: -1V to -13V DC
- Temp Range: -52°C to +177°C
- Cable Type: 75Ω FEP coaxial
- Resistance: 5.9Ω ±0.9Ω
Installation Guide
- Mounting Torque: 5.1 N•m max
- Target Distance: 1.0mm optimal
- Cable Bend: Minimum 25.4mm radius
- Thread Depth: Max 12mm
Compatibility Notes
Fits all 3300 XL NSv systems. Direct replacement for older 3300 RAM probes. Better chemical resistance than previous models.
Certifications
Meets multiple global safety standards (Option 05).
Package Details
- 1x Protected connector probe
- Factory documentation
- 12-month coverage
- Shipping: FedEx, UPS, DHL options
Important Questions
Q: Why use connector protector?
A: Prevents damage during installation in tight spaces.
Q: What cable comes with probe?
A: 7.0m standard FEP coaxial cable.
Q: Can monitor small shafts?
A: Yes, down to 8.9mm (13mm recommended).
Q: Pressure rating?
A: Viton O-ring sealed (special tests available).
