Description
Bently Nevada 3300 NSv Proximity Probe – Premium Vibration Monitoring
New & original factory-sealed probe with 12-month warranty. Ideal for industrial machinery health monitoring.
Complete Specifications
Brand: Bently Nevada
Full P/N: 330903-00-03-70-11-05
Suffix Details:
00 (0mm unthreaded) | 03 (30mm case) | 70 (7.0m length) |
11 (ClickLoc/FluidLoc) | 05 (Multi-certified)
| Parameter | Value |
| Range | 1.5mm (60 mils) |
| Accuracy (DSL) | ±0.06mm (±2.3 mils) |
| Output Signal | 7.87 V/mm (200 mV/mil) |
| Temp Range | -52°C to +177°C |
| Probe Resistance | 5.9Ω ±0.9Ω |
Installation Guide
- Gap Setting: 1.0mm (40 mils)
- Torque: Finger tight + max 0.56 N•m
- Min Bend Radius: 25.4mm (1.0in)
- Thread Engagement: 12mm max (M8x1)
Package & Support
Includes: Probe, connector protector, docs
Warranty: 12 months
Shipping: FedEx/UPS/DHL worldwide
FAQ
Q: Minimum target size?
A: 8.9mm diameter (13mm recommended)
Q: Max cable length?
A: 305m (1000ft) with shielded triad cable
Q: Pressure rating?
A: Viton O-ring seal (contact for pressure testing)
