Bently Nevada 330903-00-05-70-02-05 3300 NSv Proximity Probes

Description

Bently Nevada 3300 NSv Long-Body Proximity Sensor

Industrial-Grade Vibration Monitoring

New 330903-00-05-70-02-05 proximity probe features 50mm extended case and standard cable. With M8X1 threading and multiple international certifications. Includes 12-month factory warranty.

Part Number Details

• Full ID: 330903-00-05-70-02-05
• Suffix Explanation:
  • First -00-: Zero unthreaded length
  • -05-: 50mm case body
  • -70-: 7.0 meter cable
  • -02-: Standard cable (non-FluidLoc)
  • -05: Multi-certified

Critical Measurements

• Probe resistance: 5.9Ω ±0.9
• Cable specs: 75Ω coaxial FEP
• Max wiring distance: 1000 feet
• Response speed: 0-10kHz range
• Thread depth: 12mm max

Performance Highlights

• Output range: -1 to -13 Vdc
• Scale factor: 200 mV/mil ±20%
• PPS tip material for durability
• Stainless steel 304 housing
• Extended 50mm case

Setup Guide

• Ideal gap: 40 mils from target
• Hand-tighten only (5 in-lb max)
• Keep 1″ minimum bend radius
• Use 0.5″ minimum target surface

Certification & Package

• Global certifications included
• Factory-sealed packaging
• Protective connector cover
• 12-month defect coverage

Worldwide Delivery

Shipped via FedEx, UPS, or DHL with tracking number. Express options available.

FAQs

Q: What does -02- mean in the part number?
A: Standard cable (different from FluidLoc option)

Q: Why choose 50mm case?
A: For installations needing deeper mounting

Q: Cable type difference?
A: Standard cable vs FluidLoc (chemical resistance)

Q: Pressure testing available?
A: Special order service only
