Description
Bently Nevada Armored Probe with Global Certifications
Product Overview
New 330904-00-10-10-01-05 armored proximity probe with worldwide approvals. Features 100mm stainless steel body and 1m cable. Ships via FedEx/UPS/DHL with 12-month warranty.
Model Identifier
- Base Model: 330904 (Armored)
- -00-: No unthreaded section
- -10-: 100mm case length
- -10-: 1.0 meter cable
- -01-: ClickLoc connector with protector
- -05: Multiple international approvals
Technical Performance
- Insulation: FEP fluoropolymer
- Cable Capacitance: 70 pF/m
- Shock Rating: 50g operational
- Seal Type: Dual Viton O-rings
- Response Frequency: DC to 10kHz
Quick Installation
- Mount 100mm body with M8x1 thread
- Set gap to 1.0mm (40 mils)
- Apply 5.1 N•m maximum torque
- Avoid sharp cable bends
Common Queries
Q: What approvals does it have?
A: Multiple global certifications (option 05)
Q: Cable replaceable?
A: No – permanently attached
Q: Chemical resistance?
A: Excellent – FEP insulation resists solvents
Q: Minimum operating temp?
A: -52°C (arctic conditions)
Get full technical documentation with approval certificates – download now! 3300 XL NSv Proximity Transducer System Datasheet
