Bently Nevada 3300 NSv Proximity Probe: Precision Industrial Sensing
???? Key Features
- Brand: Bently Nevada
- Model: 330904-00-24-10-02-05 (M8X1 thread, armored)
- Condition: New & original in factory packing
- Warranty: 12 months
???? Technical Specifications
| Range | 1.5 mm (60 mils) |
| Accuracy | ±0.06 mm (±2.3 mils) DSL |
| Output Signal | 7.87 V/mm ±20% |
| Resistance | 4.2Ω ±0.5Ω (1m cable) |
| Temperature | -52°C to +177°C |
| Tip Material | PPS polymer |
| Case Material | AISI 304 stainless steel |
???? Installation Guide
- Gap Setting: 1.0 mm (40 mils)
- Torque: 5.1 N•m (finger tight)
- Max Bend Radius: 25.4 mm
- Thread engagement: 12 mm max
???? Compatibility
Works with Bently Nevada 3300 RAM probes and extension cables. Superior chemical resistance vs. older models.
Package & Shipping
- Factory-sealed with all accessories
- Shipping: FedEx / UPS / DHL
- Warranty: 12 months
FAQs
Q: Minimum target size?
A: 8.9 mm diameter (13 mm recommended)
Q: Cable length options?
A: 0.5m, 1m, 5m, 7m (This unit: 1 meter)
Q: Pressure rating?
A: Viton O-ring seal (contact for pressure testing)
