330907-05-30-50-12-00 Bently Nevada Reverse Mount Probe

Description

Bently Nevada 3300 NSv Probe: Industrial-Grade Vibration Monitoring

Core Specifications

• Full Product ID: 330907-05-30-50-12-00
• Breakdown:
  • 330907: Base model
  • 05: M10x1 thread
  • 30: Standard configuration
  • 50: 5.0 meter cable
  • 12: Mini ClickLoc connector
  • 00: No agency approvals
• Measurement Range: 0.25-1.75mm (10-70 mils)
• Accuracy: ±0.7Ω resistance tolerance

Advanced Technical Parameters

• Electrical:
  • Output signal: -1V to -13V DC linear
  • Cable resistance: 5.3Ω ±0.7
  • Max wiring distance: 305m (1000 ft)
• Mechanical:
  • Thread engagement: 15mm max
  • Housing torque: 7.5 N·m (recommended)
  • Probe weight: 14-150g
  • Seal type: Viton O-ring
• Environmental:
  • Operating temp: -52°C to +177°C
  • Storage temp: -52°C to +177°C
  • Min safe temp: -34°C (short exposure)

Installation Notes

• Mounting: Reverse configuration with M10x1 thread
• Gap setting: Optimal at 1.0mm from target
• Wiring: Use shielded triad cable (16-24 AWG)
• Critical: Avoid sustained temperatures below -34°C

Compatibility & Connections

• Works with 3300 XL NSv Proximitor systems
• ClickLoc miniature coaxial connector
• FluidLoc cable technology
• Fits thread types: M8x1, M10x1, 1/4-28, 3/8-24

Certification & Origin

• Made in USA
• Agency approvals: Not required (option 00)

Packaging & Support

• Includes probe assembly only
• 12-month manufacturer warranty
• Shipping: FedEx / UPS / DHL worldwide

Technical FAQ

• Q: Minimum thread engagement depth?
  A: 15mm for M10x1 threading
• Q: Cable fluid resistance rating?
  A: FluidLoc technology prevents ingress
• Q: Pressure seal material?
  A: Viton O-ring for differential pressure
• Q: Weight impact on small machinery?
  A: Ultra-light 14g minimum weight
