Bently Nevada 330907-05-30-50-12-CN Reverse Mount Probe

Description

Bently Nevada 3300 NSv Reverse Mount Probe

Industrial-Grade Precision Sensor

Boost your machinery monitoring with the Bently Nevada 3300 NSv Probe (Model: 330907-05-30-50-12-CN). Designed for challenging environments, this U.S.-made sensor features superior chemical resistance compared to RAM probes. Its advanced side-view technology delivers better accuracy than 3000-series probes at identical target distances. With gold-plated ClickLoc connectors and patented TipLoc molding, it ensures reliable performance in critical applications like process compressors.

Technical Specifications

• Brand: Bently Nevada

• Full Model: 330907-05-30-50-12-CN
• – Threads: M10X1 reverse mount
• – Cable: 5.0 meters (16.4 ft) FluidLoc
• – Connector: Mini coaxial ClickLoc
• – Approvals: Country Specific (CN)

• Range: 1.5 mm (0.25-1.75mm linear)

• Output: -1 to -13 Vdc

• Resistance: 5.3 ± 0.7 ohms (5.0m)

• Temp Range: -52°C to +177°C

• Accuracy: ±0.5% full scale

• Weight: 14-150 g (0.5-5.3 oz)

Installation Guide

• Optimal Gap: 1.0 mm (40 mils)

• Torque: Max 22.6 N•m – Use 7.5 N•m

• Wiring: 0.2-1.5 mm² shielded triad cable

• Max Distance: 305m to monitor

• Warning: Avoid sustained exposure below -34°C to prevent seal damage

Certifications

Meets Country-Specific safety standards (CN option). Pressure-sealed with Viton O-ring for differential pressure environments.

What’s Included

• – 3300 NSv Probe assembly
• – 12-month manufacturer warranty

• Shipped worldwide via FedEx/UPS/DHL

Common Questions

What’s the operating voltage?
-18 to -26 Vdc power supply required
Can I use this underwater?
Designed for oil/chemical resistance, not submersion
How often should probes be replaced?
Typically 3-5 years depending on environment
Is calibration required?
Factory-calibrated; field verification recommended
