Description
Bently Nevada Industrial Vibration Probe – Model 86691-01780-1300-15-00
Precision vibration sensor for critical machinery monitoring. Factory-calibrated with 4-20mA output. IP65 rated for tough environments.
???? Core Specifications
- Brand: Bently Nevada
- Model: 86691-01780-1300-15-00
- Range: ±1.5g to ±100g
- Output: 4-20mA analog
- Frequency: 1Hz-5kHz
- Temp Range: -40°C to +85°C
- Cable: 2m standard (custom lengths)
???? Technical Performance
| Response Time | <10 ms |
| Signal Noise | <2% full scale |
| Housing | Stainless steel |
| Dimensions | 35mmØ × 150mm |
| Mounting | M10×1 thread or flange |
| Shock Survival | 500g peak (11ms) |
⚡ Electrical Specifications
- Power: 24VDC ±10%
- Current: 4-20mA loop
- Connection: 2-pin terminal
- Isolation: >100MΩ
???? Environmental Ratings
- IP65 protection
- Operating temp: -40°C to +85°C
- Storage temp: -50°C to +100°C
- Humidity: 0-95% non-condensing
???? Compliance & Certifications
- CE certified
- RoHS compliant
- UL listed
⚙️ Installation Guide
- Mounting torque: 15-20 N·m
- Alignment tolerance: <1°
- Cable bend radius: >50mm
????️ Maintenance & Diagnostics
- Zero-point calibration every 6 months
- Check signal noise levels
- Inspect housing for damage
???? Package Contents
- Vibration probe unit
- 2-meter cable
- Mounting hardware kit
- 12-month warranty
✈️ Shipping Options
FedEx Priority | UPS Worldwide | DHL Express
???? Application Scenarios
- Power Plant: Turbine bearing monitoring
- Water Treatment: Pump vibration analysis
- Manufacturing: Conveyor system diagnostics
- Mining: Crusher equipment protection
❓ Technical FAQ
Q: Can output be converted to voltage?
A: Yes, use 250Ω resistor for 1-5V output
Q: Minimum detectable vibration?
A: 0.05g RMS at 10Hz
Q: Custom cable lengths available?
A: Yes, 1m to 20m options
Q: Response time in high-vibration areas?
A: <5ms at >50g loads
