MTL3073 Temperature Transmitter: Connect Sensors Safely
The MTL3073 is a smart signal converter. It takes readings from temperature sensors in hazardous areas and converts them into a safe 4-20mA signal. It works with many sensor types and is easy to set up with a computer.
Technical Details
Brand & Model: MTL MTL3073 Temperature Transmitter
Input Types: J, K, T, E, R, S, B, N Thermocouples / 2-3-4 wire RTDs (100Ω Pt)
Output Signal: 4 to 20mA (Direct or Reverse)
Maximum Load: 600Ω
Power Supply: 20-35V DC
Power Consumption: ~57mA at 24V
Calibration Accuracy: Better than ±0.05%
Isolation: 250V AC
Operating Temp: -20°C to +70°C
Default Config: Type K Thermocouple, 0-250°C range
Setup & Use
Mount on a standard DIN rail. Connect your sensor and power. Use the PCS45 software on a PC to easily set your desired temperature range and sensor type. The MTL3073 is ready for use.
Frequently Asked Questions
- Q1: What software do I need to configure it?
A1: You need MTL’s PCS45 software and a PCL45 interface connected to a PC. - Q2: Does it compensate for cold junction temperature?
A2: Yes, it has a built-in sensor for automatic cold junction compensation (CJC). - Q3: What happens if my temperature sensor fails?
A3: You can configure the output to drive upscale or downscale to trigger an alarm. - Q4: Can I use it with a 3-wire RTD?
A4: Yes, the MTL3073 supports 2-, 3-, and 4-wire platinum RTD connections. - Q5: What is the default output range?
A5: It comes preset for 0-250°C for a Type K thermocouple.
Package & Delivery
Includes one MTL3073 unit. We ship globally using FedEx, UPS, and DHL for fast delivery.
Your Product Guarantee
This product is covered by a 12-month warranty from the date of purchase.
