Description
Allen-Bradley 1734-IB2 DC Sinking Input Module
The Allen-Bradley 1734-IB2 from Rockwell Automation provides reliable DC sinking input capabilities. This compact module integrates perfectly into the POINT I/O 1734 series for industrial control applications. It offers two input channels for connecting various field devices and sensors. For complete installation and configuration details, download the manual here: POINT I/O ASCII Modules Manual.
Technical Specifications
- Brand & Manufacturer: Allen-Bradley (Rockwell Automation)
- Part Number & Model: 1734-IB2
- Product Series: POINT I/O 1734 Series
- Module Type: Digital DC Sinking Input Module
- Number of Inputs: 2 sinking inputs
- Input Voltage: 24 Volts DC nominal
- Operating Voltage Range: 10-28.8 Volts DC
- Maximum Input Current: 5 milliamps per input
- Input Impedance: 4.8 kiloohms nominal
- POINTBus Current: 75 milliamps at 5V DC maximum
- Power Dissipation: 0.7 Watts maximum at 28.8V DC
- Thermal Dissipation: 2.4 BTU/hour maximum
- Response Time: On: 2ms typical, Off: 10ms typical
- Isolation Voltage: 50V DC continuous
- Terminal Screw Torque: 0.8 N-m (7 lb-in)
- Operating Temperature: -20°C to 55°C (-4°F to 131°F)
- Storage Temperature: -40°C to 85°C (-40°F to 185°F)
- Relative Humidity: 5-95% non-condensing
- Dimensions: 56 x 12 x 75.5 mm (WxHxD)
- Weight: 30.9 grams (1.09 ounces)
- Enclosure Type: Open-style
- Mounting: Horizontal or vertical DIN rail
- Connection Type: Removable Terminal Block (RTB)
Packaging & Shipping
- Includes one (1) Allen-Bradley 1734-IB2 DC sinking input module
- All products include comprehensive 12-month warranty coverage
- Global shipping via FedEx, UPS, and DHL express carriers
- Standard delivery within 3-7 business days worldwide
