Allen-Bradley 1762-IQ16 | 16-Channel DC Input Module
Get a quote today! This high-density input module includes our 12-month warranty and ships fast worldwide via FedEx, UPS, or DHL.
Product Overview
The Allen-Bradley 1762-IQ16 is a compact 16-channel DC input module. It expands MicroLogix 1100, 1200, and 1400 controllers. It connects switches and sensors to your control system.
Detailed Technical Specifications
- Brand & Model: Allen-Brady 1762-IQ16
- Compatible Controllers: MicroLogix 1100, 1200, 1400
- Module Type: Digital DC Input Module
- Input Channels: 16 sinking/sourcing
- Voltage Range: 10-30V DC (24V DC nominal)
- On-State Voltage: ≥10V DC
- On-State Current: 2.0-12.0 mA (depending on voltage)
- Off-State Voltage: ≤5V DC
- Off-State Current: ≤1.5 mA
- Response Time: 8.0 ms (ON to OFF and OFF to ON)
- Power Consumption: 3.7W maximum
- Commons: 2
- Enclosure Rating: IP20
- Operating Temperature: 0°C to 55°C (32°F to 131°F)
- Dimensions: 90 x 40 x 87 mm (3.54 x 1.59 x 3.43 in)
- Weight: 0.3 kg (0.66 lbs)
Installation & Compatibility
The 1762-IQ16 connects directly to MicroLogix controllers with a ribbon cable. It mounts on DIN rail or panel. Follow proper grounding practices to avoid electrical noise issues.
Frequently Asked Questions
Q1: What devices can I connect to this module?
A1: You can connect limit switches, proximity sensors, push buttons, and other 10-30V DC field devices.
Q2: What is the difference between sinking and sourcing?
A2: Sinking devices receive current, sourcing devices provide current. This module works with both types.
Q3: How many modules can I connect to my controller?
A3: MicroLogix 1100: 4 modules, 1200: 6 modules, 1400: 7 modules maximum.
Q4: What is the response time of the inputs?
A4: All channels have an 8ms response time for both ON and OFF transitions.
Q5: Is this module suitable for wet environments?
A5: No, the IP20 rating means it’s for dry, indoor use only. It needs protection in damp or wet areas.
