Allen-Bradley 1762-OB8 – 8-Point 24VDC Output Module | MicroLogix

Description

Allen-Bradley 1762-OB8: 8-Point 24VDC Sourcing Output Module

The Allen-Bradley 1762-OB8 expands your MicroLogix system with eight reliable sourcing outputs. This Rockwell Automation module delivers robust performance for industrial control applications.

Core Technical Specifications

• Brand: Allen-Bradley
• Model: 1762-OB8
• Module Type: 24VDC Sourcing Output
• Number of Outputs: 8 points
• Operating Voltage Range: 20.4-26.4V DC
• On-State Delay Time: 0.1 ms maximum
• Off-State Delay Time: 1.0 ms maximum
• Maximum Continuous Current: 0.5A per point
• Total Module Current: 4.0A maximum
• Surge Current Capacity: 2.0A for 10ms
• Backplane Current Draw: 115 mA at 5V DC
• Power Dissipation: 1.6 Watts operational

Environmental & Durability Ratings

• Operating Temperature: 0 to 55°C (32 to 131°F)
• Storage Temperature: -40 to 85°C (-40 to 185°F)
• Relative Humidity: 5% to 95% non-condensing
• Maximum Altitude: 2000 meters (6561 feet)
• Shock Resistance: 30G operational rating
• Vibration Resistance: 5G at 500 Hz frequency
• Isolation Rating: 1200V AC (1697V DC) for 1 second

Packaging & Shipping Details

• Package includes one 1762-OB8 module
• Shipping dimensions: 90 × 87 × 40.4 mm
• Product weight: 210 grams
• Global shipping via FedEx, UPS, and DHL
• Standard delivery with tracking number

Comparison With Related Products

• The 1762-OB8 provides 8 digital outputs
• Compare with the 1762-IQ8OW6 combination I/O module
• Or the 1762-IR4 RTD input module
• This module specializes in 24VDC output control applications
