Description
Allen-Bradley 22D-D010F104 PowerFlex Drive – 5HP Industrial Powerhouse
Built for: The Allen-Bradley 22D-D010F104 delivers robust 5HP motor control for demanding industrial applications like material handling and packaging systems.
Complete Technical Specifications
- Model: 22D-D010F104 (PowerFlex 40P Series)
- Power: 5 HP (4.0 kW) output
- Voltage: 480V AC (3-phase)
- Current: 10.5 Amps
- Dimensions: 244 x 250 x 182 mm
- Weight: 4.5 kg (9.9 lbs)
- Control Methods: V/Hz, Sensorless Vector
- Safety: Category 3 Safe Torque Off
- Display: HMI with reset function
- Braking: Dynamic braking capability
- Mounting: Flange (IP20 enclosure)
Expert Answers to Common Questions
- What’s the minimum voltage requirement?
- Needs at least 380V AC to operate properly.
- Can I use this for elevator applications?
- Not recommended for lifting applications.
- How many preset speeds can I program?
- Supports multiple preset speeds via digital inputs.
- Is dynamic braking included?
- Capability is built-in but requires external resistor.
- What’s the warranty coverage period?
- Full 12-month protection against defects.
Package & Shipping Information
- 12-month quality guarantee
- Fast worldwide delivery options
- Secure packaging with protective materials
Similar PowerFlex Drives
- 22D-D024N104 (Higher current 24A version)
- 22D-D1P4F104 (Lower power 1.4A model)
