Allen-Bradley 1771-HODS Converter Option ODS Module | Motion Control Interface
The Allen-Bradley 1771-HODS provides critical interface capabilities for Rockwell Automation’s 123 Motion Control System. This versatile module enables extended connectivity for both ODS terminals and handheld pendants, enhancing operational flexibility in industrial automation environments.
Technical Specifications
- Brand: Allen-Bradley / Rockwell Automation
- Model Number: 1771-HODS
- Series Compatibility: PLC-5
- Product Type: Converter Option ODS Module
- Communication Protocols: RS-232, RS-422
- Termination Panels: 4 Available Configurations
- Handheld Pendant Distance: 8m (25ft) standard, 393m (1200ft) with longline
- ODS Terminal Distance: 393m (1200ft) maximum
- Longline Option: Compatible with 1771-HLL Module
- Operating Voltage: 24V DC ±10%
- Current Consumption: 850mA @ 24V DC
- Data Transfer Rate: Up to 115.2 kbps
- Isolation Voltage: 1500V AC
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -40°C to 85°C (-40°F to 185°F)
- Relative Humidity: 5% to 95% non-condensing
- Mounting: DIN Rail
- Enclosure Rating: IP20 for indoor use
- Weight: 1.2 kg (2.65 lbs)
Installation & Setup
- Simple DIN rail mounting requires minimal space
- Clear labeling ensures proper connection of peripherals
- Comprehensive documentation guides installation process
- No special tools required for basic installation
- Tested for compatibility with PLC-5 processor family
Packaging & Delivery
- Each 1771-HODS module includes mounting hardware
- Protected packaging prevents damage during transit
- Worldwide shipping via FedEx, UPS, and DHL
- Express delivery options available for urgent requirements
- Order processing typically completes within 1-2 business days
Frequently Asked Questions
- Q: What is the maximum distance for pendant operation?
A: Standard operation supports 8 meters, extendable to 393 meters with longline option - Q: Does this module require special configuration software?
A: No special software needed; integrates directly with 123 Motion Control System - Q: Can I use multiple 1771-HODS modules in one system?
A: Yes, multiple modules can be integrated for expanded connectivity - Q: What types of resolvers does the resolver panel support?
A: Supports both single and dual resolver configurations - Q: Is the module compatible with newer ControlLogix systems?
A: The 1771-HODS is specifically designed for PLC-5 and 123 Motion Control systems
Comparison Products
Explore other Allen-Bradley modules: 1771-ID16 Input Module and 1771-IFE Analog Input Module.
