Bently Nevada 102244-22-50-01 Vibration Transmitter: Precision Machinery Monitoring
Core Function & Design
Tri-mode vibration transmitter measuring acceleration, velocity, and displacement. Converts mechanical vibration into 4-20mA/RS-485 signals for predictive maintenance systems.
Technical Specifications
| Model | 102244-22-50-01 |
| Measurement Range | Acceleration: 0.1-50 g Velocity: 0.1-10 in/s Displacement: 0.1-10 mil |
| Frequency Range | 10 Hz – 10 kHz |
| Output Signals | 4-20 mA analog 0-10 V analog RS-485 digital |
| Power Supply | 24 VDC ±10% |
| Temperature Range | -40°C to +85°C (-40°F to 185°F) |
| Protection Class | IP65 (dust/water resistant) |
| Dimensions | 150 x 75 x 45 mm (5.9 x 3.0 x 1.8 in) |
How It Works
Measures vibration through internal MEMS sensor. Converts mechanical motion to electrical signals. Transmits real-time data via analog/digital outputs for condition monitoring.
Installation
- Mount on machine surface with M6 screws
- Connect to 24VDC power source
- Wire outputs to control system
- Ensure grounding for noise protection
Compatibility
Integrates with Bently Nevada 3500 systems, PLCs, and SCADA via 4-20mA or RS-485 protocols.
Packaging
- Vibration transmitter unit
- Mounting hardware kit
- Quick-start guide
Shipping & Warranty
- Global delivery via FedEx, UPS, DHL
- 12-month manufacturer warranty
Maintenance
- Check mounting torque annually
- Clean sensor surface quarterly
- Verify signal output during shutdowns
FAQ
Q: Digital communication protocol?
A: RS-485 with Modbus RTU standard.
Q: Hazardous area certified?
A: Standard model for non-hazardous areas only.
Q: Calibration required?
A: Factory calibrated. Field recalibration every 24 months.
