Bently Nevada 163179-02 3500 Series Temperature Monitoring Module

Description

Product Overview

• Brand: Bently Nevada
• Model: 163179-02
• Series: 3500
• Module Type: 3500/61 Temperature Monitor
• This module delivers reliable multi-channel temperature monitoring.
• It supports both RTD and thermocouple sensors.
• Six independent channels ensure wide system coverage.
• Each channel includes a dedicated recorder output.
• It suits critical industrial protection applications.

Core Functional Advantages

• User-programmable alarm thresholds improve system safety.
• Supports Alert and Danger alarms with delay control.
• High input impedance reduces signal loading.
• Recorder outputs simplify external trend analysis.
• Optional isolated TC I/O enhances noise immunity.

Technical Specifications

• Input Channels: 1 to 6 RTD or TC signals
• Input Impedance: 10 MΩ per lead
• Resolution: 1 °C or 1 °F
• Accuracy: ±3 °C at 25 °C
• Linearity: Maintained across full-scale range
• Recorder Output: 4–20 mA proportional signal
• Load Compliance: Up to 600 Ω
• Power Consumption: 9 W nominal

Measurement Ranges

• Type K thermocouple supports up to 1370 °C.
• Platinum RTDs cover -200 °C to +850 °C.
• Nickel RTDs suit medium temperature ranges.
• Copper RTDs enable precise low-range sensing.

Environmental and Reliability Performance

• Operating Temperature: -30 °C to +65 °C
• Storage Temperature: -40 °C to +85 °C
• Designed for harsh industrial environments.
• Strong resistance to electrical interference.

Installation Guide

• Mount the module in a Bently Nevada 3500 rack.
• Select the correct RTD or TC I/O module.
• Wire sensors according to the terminal layout.
• Verify grounding to reduce noise.

Commissioning and Maintenance

• Configure channels using 3500 Rack Configuration Software.
• LED indicators provide fast status checks.
• Modular design enables quick replacement.
• Minimal calibration effort required.

Compatibility

• Compatible with all 3500 series racks.
• Supports non-isolated and isolated I/O modules.
• Works with standard industrial RTD and TC sensors.

Certifications and Compliance

• SIL 2 functional safety certified.
• Complies with EMC Directive 2014/30/EU.
• Meets EN 61010-1 electrical safety standard.
• Approved for ATEX and IECEx hazardous areas.

Typical Applications

• Turbine bearing temperature monitoring.
• Motor and generator protection systems.
• Oil and gas process equipment.
• Marine and offshore machinery.

Diagnostic Capabilities

• Continuous signal validation improves reliability.
• Alarm logs support fault analysis.
• Recorder outputs aid trend diagnostics.

Package Contents

• One Bently Nevada 3500/61 monitor module.
• Protective industrial packaging.
• Factory inspection label.

Warranty and Shipping

• Standard warranty: 12 months.
• Fast delivery via FedEx, UPS, or DHL.
• Secure packaging for global transport.

FAQ

• Can one module mix RTD and TC inputs?
• Each module supports one sensor type per configuration.
• Is isolation necessary in high-noise sites?
• Isolated TC I/O improves stability in noisy environments.
• How do I choose between 3500/60 and 3500/61?
• Select 3500/61 when recorder outputs are required.
• What is a common field practice?
• Engineers often reserve two spare channels for expansion.

Buying Guidance

• Confirm sensor type before ordering.
• Check isolation needs for your site.
• Plan spare capacity for future growth.
