Description
Product Overview
This is the Bently Nevada 31000-28-05-70-066-00-02 housing assembly. It is a protective enclosure for 8 mm vibration probes. The housing has a tough plastic body with metal parts. It protects the probe from water, dust, and impacts. Ideal for use in harsh industrial environments.
Understanding the Part Number
Main Product: 31000 (Probe Housing Assembly)
Configuration Suffix:
- -28- Probe Type: For 3300 XL 8 mm Probe (with approvals)
- -05- Cable Length: 0.5 inch (at housing exit)
- -70- Standoff Length: 7.0 inches (extends from mount)
- -066- Probe Reach: 6.6 inches (inside the housing)
- -00- Fittings: No extra fittings included
- -02 Mounting Thread: 3/4-14 NPT (for pipe installation)
Key Features & Advantages
- Rugged Protection: Meets NEMA 4X and IP66 ratings. It keeps water and dust out of the probe.
- Hazardous Area Safe: Made with special conductive plastic. It prevents static electricity in dangerous locations.
- Strong Construction: Can survive strong impacts at very high and low temperatures.
- Easy Installation: Standard 3/4-14 NPT thread allows simple mounting on pipes or machines.
- Complete Solution: Part of the 31000 Proximity Probe Housing Assemblies line.
Technical Specifications
- Product Identification
- Brand: Bently Nevada
- Full Model: 31000-28-05-70-066-00-02
- Type: Probe Protective Housing
- Series: 31000
- Physical Details
- Body Material: Conductive Glass-Reinforced PPS Plastic
- Metal Parts: 304 & 303 Stainless Steel
- Seals: Neoprene O-Rings
- Mounting: 3/4-14 NPT Thread
- Nut Torque: 29.4 N·m
- Weight: 1.2 kg
- Environmental Ratings
- Temperature: -51°C to +105°C
- Enclosure: NEMA 4X, IP66 (Water and Dust Tight)
- Impact Tested: Certified for high energy impacts.
- Hazardous Area: Conforms to CENELEC EN50014.
Installation Guide
- Mount the housing using the 3/4-14 NPT thread.
- Insert your 3300 XL 8 mm probe into the housing.
- Tighten the housing retaining nut to 29.4 N·m.
- Ensure the cable exits the housing properly.
- Check that all seals are in place and clean.
Support & Ordering Information
- Warranty: Comes with a 12-month manufacturer warranty.
- Shipping: Shipped worldwide via FedEx, UPS, or DHL.
- Compatibility: Designed for Bently Nevada 3300 XL 8 mm probes.
- Need Help? Contact our engineers on WhatsApp: +86 158 8020 0923.
Expert FAQs
Product Application
- Q: What does “Standoff Adapter” mean in this housing?
- A: The standoff (7.0 inches here) is a metal tube. It spaces the probe away from the mounting point. This lets you install the probe deeper into a machine case that has a thick wall.
Specifications & Use
- Q: Can I use this housing with a 5 mm or 11 mm probe?
- A> No. This specific -28- version is only for 8 mm probes. You need a different housing model for other probe sizes.
- Q: What is the benefit of the conductive plastic housing?
- A: In areas with flammable gases or dust, static sparks can cause fires. The conductive material safely drains any static charge to ground, preventing sparks.
Selection & Sourcing
- Q: The suffix is “-00-” for fittings. What does that mean?
- A> It means this housing ships without extra connection parts like unions or elbows. You provide the needed pipe fittings for your specific installation.
- Q: Based on field experience, when is this housing most critical?
- A: It is essential outdoors or in wash-down areas. The IP66 rating protects the expensive probe inside from high-pressure water jets used for cleaning. It prevents water damage failures.
