Bently Nevada 3300 NSv Proximity Probe: High-Performance Vibration Monitoring
Product Description
Bently Nevada’s 330904-00-10-70-01-05 proximity probe delivers superior vibration monitoring for critical machinery. Features M8x1 threading with stainless steel armor and chemical-resistant PPS tip. Direct replacement for legacy 3300 RAM probes with enhanced performance.
Key Technical Specifications
- Brand: Bently Nevada
- Model: 3300 NSv Proximity Probe [Full Suffix: 00-10-70-01-05]
- Linear Range: 0.25-1.75mm (10-70 mils)
- Accuracy: ±0.06mm deviation from best-fit line
- Output Signal: -1 to -13 Vdc (7.87 V/mm scale factor)
- Temp Range: -52°C to +177°C (operating & storage)
- Resistance: 5.9Ω ±0.9Ω (probe), 0.220Ω/m (cable)
Installation Guide
- Optimal Gap: 1.0 mm (40 mils) from target
- Torque: Finger tight + max 0.56 N•m
- Thread Engagement: 12mm max for M8x1
- Bend Radius: >25.4mm (1.0 in)
Compatibility & Upgrades
Fully interchangeable with 3300 RAM probes. Superior to 3000-series 190 probes in side-view characteristics and chemical resistance. Compatible with all 3300 XL NSv Proximitor Sensors.
What’s Included
- 3300 NSv Probe (7m cable)
- Miniature coaxial ClickLoc connector
- Connector protector
- Factory packaging
- 12-month warranty card
Frequently Asked Questions
Q: What cable length options exist?
A: Available in 0.5m, 1m, 5m, and 7m (this model).
Q: Minimum target size?
A: 8.9mm diameter (13mm recommended).
Q: Pressure rating?
A: Seals differential pressure via Viton O-ring (contact for pressure testing).
