Description
Bently Nevada 3300 NSv Short Armored Proximity Probe
New factory-packed vibration sensor with extra-long 150mm case and short 0.5m cable.
Part Number Breakdown
Complete ID: 330904-00-15-05-02-05
- Base: 330904 (Armored probe)
- First -00-: 0mm unthreaded length
- -15-: 150mm case length
- -05: 0.5 meter cable
- -02: Standard cable with ClickLoc
- -05: Certified for multiple standards
Technical Specifications
| Brand | Bently Nevada |
| Cable Length | 0.5 meters (20 inches) |
| Case Length | 150 mm |
| Probe Resistance | 4.0Ω ±0.5Ω |
| Min Bend Radius | 25.4 mm (1.0 inch) |
Performance Details
- Measuring Range: 1.5 mm
- Accuracy: ±0.06 mm
- Temp Range: -52°C to +177°C
- Response Speed: 0-10 kHz
- Thread Type: M8x1
Installation Notes
- Set gap to 1.0 mm from target surface
- Hand tighten only – do not overtighten
- Max thread depth: 12 mm
- Keep cable bends gentle
Works With
- 3300 XL NSv Proximitor Sensors
- Older 3300 RAM systems
- Shielded triad field wiring
What’s Included
- Armored probe unit
- Connector protector cap
- Factory paperwork
- 12 month warranty
Shipping Methods
- FedEx Express
- UPS Air
- DHL Worldwide
Common Questions
Q: Why choose short cable version?
A: Ideal for tight spaces with nearby monitors
Q: What does 150mm case mean?
A: Longer body for hard-to-reach measurement points
Q: Is this waterproof?
A: Features Viton O-ring but not pressure tested
Q: Can I connect extension cables?
A: Yes, use shielded triad cable up to 305m
