Bently Nevada 3300 NSv Proximity Probe | 330904-08-15-50-02-00

Description

Bently Nevada 3300 NSv Proximity Probe 330904-08-15-50-02-00: Precision Vibration Monitoring

New factory-sealed probe with M8X1 thread and 5m armored cable. Features enhanced chemical resistance for tough industrial environments. Includes 12-month warranty.

Complete Part Number Breakdown

• 330904: Base model (M8X1 threaded)
• -08-: 80mm unthreaded length
• -15-: 150mm case length
• -50-: 5.0 meter cable
• -02-: ClickLoc coaxial connector
• -00-: No agency approval required

Technical Specifications

• Brand/Model: Bently Nevada 3300 NSv
• Linear Range: 1.5mm (10-70 mils)
• Sensitivity (ISF): 7.87 V/mm ±12.5%/-20%
• Frequency Response: 0-10 kHz (±3dB)
• Probe Resistance: 5.3Ω ±0.7 (5m cable)
• Temp Range: -52°C to +177°C
• Housing Material: AISI 304 stainless steel
• Tip Material: Chemical-resistant PPS

Installation Guide

• Mounting Torque: Finger tight (max 0.56 N•m)
• Thread Engagement: Max 12mm for M8X1
• Min Bend Radius: 25.4mm (with/without armor)
• Cable Type: Shielded triad (max 305m)

Shipping & Support

• Warranty: 12 months
• Shipping: FedEx/UPS/DHL global
• Condition: New in factory packaging

Frequently Asked Questions

• Q: Compatible with 3300 RAM systems?
  A: Yes, fully interchangeable
• Q: Minimum target size?
  A: 8.9mm diameter (13mm recommended)
• Q: Pressure rating?
  A: Viton sealed (contact for pressure testing)

Download product manual: Click here for installation guide
