Product Description
The 3300 XL 11 mm Proximity Probes from Bently Nevada deliver reliable shaft vibration and position monitoring. Model 330703-000-060-10-02-CN uses a M14 x 1.5 thread without armor. It has a 60 mm overall case length and a 1.0 metre total cable length. The probe includes a miniature coaxial ClickLoc connector for secure attachment. This sensor works in harsh industrial environments like turbines and compressors. Each unit ships new in original factory packing with a 12-month warranty.
Technical Specifications
- Brand: Bently Nevada
- Model: 330703-000-060-10-02-CN
- Series: 3300 XL 11 mm Metric
- Measurement range: 0 to 4.6 mm (0 to 180 mil)
- Frequency response: 0 to 10 kHz
- Sensitivity: 7.87 mV/µm (200 mV/mil)
- Linearity: within ±0.05 mm from 0.5 to 2.5 mm gap
- Resolution: 0.1 µm typical
- Probe tip material: Polyphenylene sulfide (PPS)
- Probe case material: AISI 304 stainless steel (SST)
- Cable type: 75 Ω triaxial, FEP insulated
- Probe DC resistance: 5.9 ± 0.5 ohms (1.0 m cable)
- Operating temperature: -52°C to +177°C (-62°F to +351°F)
- Storage temperature: -52°C to +177°C
- Low temperature caution: Below -34°C may damage pressure seal
- Environmental protection: Rated for EPL Ga, Gc, Dc
- 60 Hz magnetic field immunity (5m system):
- At 0.5 mm gap: 0.001 mV pp/gauss
- At 2.5 mm gap: 0.009 mV pp/gauss
- At 4.6 mm gap: 0.027 mV pp/gauss
Ordering Information Breakdown
- 330703 = 3300 XL 11 mm Probe, M14x1.5 thread, no armor
- 000 = 00 mm unthreaded length
- 060 = 60 mm overall case length
- 10 = 1.0 metre total length (3.3 feet)
- 02 = Miniature coaxial ClickLoc connector, standard cable
- CN = Country specific agency approval
Installation Guide
- Use recommended torque: 21.1 N·m (187 in·lb)
- Maximum torque allowed: 63.3 N·m (560 in·lb)
- Thread engagement length: 21 mm max
- Do not expose probe below -34°C before installation
- Keep cable bends gentle to avoid damage
Calibration & Maintenance Convenience
- Factory calibrated for gap vs output voltage
- No field calibration needed under normal use
- Easy cleaning of probe tip with soft cloth
- Inspect cable and connector for wear every 6 months
Compatibility
- Works with Bently Nevada 3300 XL extension cables
- Compatible with 3300 XL proximity system monitors
- Pairs with 8 mm or 5 mm probes in same system
- Accepts standard 75 ohm coaxial extensions
Certifications
- EPL Ga and Gc for gas environments
- EPL Dc for dust environments
- Temperature class T1 to T5 for ambient (probe only)
- Country specific approval: CN
Packaging & Warranty
- Condition: New & original in factory packing
- Warranty: 12 months from Bently Nevada
- Each probe includes connector and full cable length
- No extra accessories needed for basic install
Shipping Methods
- FedEx priority available
- UPS express worldwide
- DHL international freight
Typical Applications & Diagnostic Ability
- Radial vibration monitoring on steam turbines
- Shaft position detection in gas compressors
- Axial thrust measurement in pumps
- Eccentricity and differential expansion
- Diagnoses bearing wear, unbalance, and misalignment
- Works with 3300 XL monitors for real-time alerts
Frequently Asked Questions (FAQ)
- What is the difference between 330703 and other 3300 XL probes? This version has M14x1.5 thread, 60 mm case, 1 m cable, no armor, and ClickLoc connector.
- Can I use this probe in a high moisture area? Yes. The FEP cable and PPS tip resist moisture well. Keep connector dry.
- How do I check if my existing extension cable works? Use only 75 ohm triaxial cable. Bently Nevada extensions are best.
- Why does resistance show 5.9 ohms for 1m probe? That is the center to outer conductor resistance. It confirms cable health.
- What happens if I over-torque the probe case? Over 63.3 N·m can strip threads or crack the case. Always stay below max.
- Can I cut the cable to a shorter length? No. Cutting changes impedance and calibration. Order exact length needed.
- Which gap should I set for best sensitivity? Set gap between 0.5 mm and 2.5 mm for linear response and low noise.
Selection Guide
- Choose unthreaded length 000 for standard mount
- Pick overall case length based on your mounting depth (060 = 60 mm)
- Select total cable length: 1, 5, or 9 meters only
- Use ClickLoc (02) for easy locking in tight spaces
- Need high temperature? Check T class against your max temp
- Avoid -34°C operation to protect pressure seal life
- For magnetic fields above 300 gauss, use 5m system or shield cable
