Description
Description
Bently Nevada 330101-00-08-10-02-CN 3300 XL 8 mm Probe delivers precision industrial sensing with a compact 3/8-24 UNF thread design. Engineered for vibration and position monitoring, this unarmored probe features patented TipLoc and CableLoc technologies, ensuring 330 N (75 lbf) pull resistance and PPS-encapsulated coil durability. Optional FluidLoc cable prevents fluid migration in oil-rich environments.
Technical Data for 330101-00-08-10-02-CN
- Brand: Bently Nevada
- Model: 3300 XL 8 mm Probe (Unarmored)
- Product Suffix Breakdown:
- -00: 0.0 in unthreaded length
- -08: 0.8 in overall case length
- -10: 1.0-meter cable (3.3 ft)
- -02: Miniature ClickLoc connector, standard cable
- CN: Country-specific certifications (ATEX/IECEx)
- Frequency Response: 0–12 kHz (±3 dB) with ≤305m field wiring
- Signal Rolloff: -1 dB @ 20 kHz (1.0m system)
- Output Impedance: 50 Ω ±10% @ 1 kHz
- Insulation Resistance: >100 MΩ @ 500 VDC
- Dielectric Strength: 500 VAC (1 min) between conductor/shield
- Radiation Hardness: Resists 100 kGy gamma radiation (ASTM E1261)
Key Enhancements:
- Dynamic Range: 120 dB (0.001–2.3 mm)
- Settling Time: <2 ms for 90% step response
- Hysteresis: <0.5% of full-scale output
- Thermal Drift: ±0.005% FS/°C (-30°C to +100°C)
Contact Support
For certification documents or custom configurations:
sales@ubestplc.com
Explore more detailed information in official datasheet here: 3300 XL 8 mm Proximity Transducer System Datasheet
