Description
Overview
The Bently Nevada 330103-05-15-10-02-00 proximity probe delivers high-precision vibration monitoring for industrial machinery. Featuring an M10×1 threaded stainless steel case and PPS probe tip, this 8 mm sensor operates reliably in extreme temperatures (-52°C to +218°C) and harsh environments. Designed for radial vibration measurement, it integrates a miniature coaxial ClickLoc™ connector and supports 305-meter field wiring for flexible installation.
Technical Specifications
| Category | Details |
|---|---|
| Brand | Bently Nevada |
| Model | 330103-05-15-10-02-00 |
| Suffix Decoding | 05: 50 mm unthreaded length 15: 150 mm case length 10: 1.0 m cable 02: ClickLoc connector 00: No agency approvals |
| Probe Tip Material | Polyphenylene Sulfide (PPS) |
| Case Material | AISI 303/304 Stainless Steel |
| Thread Type | M10×1 (max 15 mm engagement) |
| Linear Range | 0.25–2.3 mm (10–90 mils), -1 to -17 Vdc |
| Gap Setting | -9 Vdc ≈1.27 mm (50 mils) |
| DC Resistance (RPROBE) | 7.59 Ω ±0.5 @1.0 m |
| Temperature Range | Standard: -52°C to +177°C Extended: -52°C to +218°C (tip), -51°C to +260°C (cable) |
| Humidity Tolerance | <3% ASF change @93% RH (IEC 68-2-3) |
| Compliance | Intrinsic Safety: AEx/Ex ia IIC T1-T5 Nonincendive: AEx/Ex nA/ec IIC T1-T5 |
