Bently Nevada 330104-01-09-10-11-05 | Armored Probe with FluidLock & ATEX

Description

Premium Armored Sensor with FluidLock Protection

The Bently Nevada 330104-01-09-10-11-05 is a top-tier industrial probe. It combines armored construction, FluidLock cable, and multiple safety approvals. This sensor is built for the most demanding environments where oil, impact, and explosions are risks.

Ultimate Protection Package

• Double Defense: Stainless steel armor plus FluidLock cable seal. Guards against physical damage and oil ingress.
• Global Compliance: Comes with multiple agency approvals (ATEX, IECEx, CSA) for worldwide projects.
• Connector Saver: Includes a protective boot on the ClickLoc connector for extra durability.
• Compact & Tough: Short 90mm armored case withstands harsh conditions in tight spaces.
• Hazard Area Ready: Suitable for Class I, Zone 0/1/2 installations with proper system design.

Part Number Configuration Guide

The code 330104-01-09-10-11-05 tells the full story:

• Root Code (330104): 3300 XL 8mm Probe, M10x1, With Armor
  • ▪ Suffix -01: Unthreaded = 10 mm
  • ▪ Suffix -09: Total Case = 90 mm
  • ▪ Suffix -10: Cable = 1.0 Meter
  • ▪ Suffix -11: Connector = ClickLoc with Protector & FluidLock Cable
  • ▪ Suffix -05: Approval = Multiple (ATEX/IECEx/CSA)

Complete Product Specifications

• Brand: Bently Nevada
• Model: 330104-01-09-10-11-05
• Type: Armored 3300 XL 8mm Proximity Probe
• Electrical Data:
  • Probe Resistance (1.0m): 7.59 Ω ± 0.50 Ω
  • System Power: -17.5 Vdc to -26 Vdc
  • Output Impedance: 50 Ω
• Mechanical Build:
  • Thread: M10 x 1.0 Metric
  • Case: Armored AISI 303/304 Stainless Steel
  • Tip: Rugged PPS Plastic
  • Seal: Viton O-ring
• Environmental Ratings:
  • Hazardous Areas: Class I, Zone 0/1/2 Capable
  • Temperature Range: See T1-T5 Schedule
  • Cable: FluidLock prevents oil wicking

Ideal Applications

• Oil & gas pumps and compressors where oil leakage is present.
• Mining equipment in dusty, high-vibration environments.
• Any location where the 3300 XL 8mm Probes cable could be exposed to fluids or impact.
• Plants requiring certified equipment for explosive atmospheres.

Order & Support Details

• Includes: One fully assembled armored probe with FluidLock cable and connector protector.
• Warranty: Protected by a solid 12-month manufacturer warranty.
• Shipping: Fast international delivery via FedEx, UPS, and DHL.
• Expert Help: Contact us on WhatsApp: +86 158 8020 0923 for application advice.

Technical FAQ

Features & Benefits

• What is the advantage of the FluidLock cable?
• It stops oil and other liquids from traveling inside the cable jacket to your connector or monitor. This protects your electronics and keeps the machine area clean.
• How does the connector protector help?
• The protective boot around the ClickLoc connector shields it from dust, moisture, and accidental impact during operation and maintenance.

Certification & Use

• What “Multiple Approvals” does this model have?
• The 330104-01-09-10-11-05 typically includes ATEX (EU), IECEx (International), and CSA (North America) certifications, making it acceptable for most global hazardous area projects.
• Can this probe be used in a Zone 0 area?
• Yes, but only when installed as part of a full intrinsically safe system per Bently Nevada drawing 141092 using approved zener barriers or isolators.

Selection & Purchasing

• This seems like a premium model. When is it worth the investment?
• Choose this model for critical applications with multiple risk factors: presence of oil, physical hazard to the cable, and requirement for certified equipment in explosive atmospheres. It is the most protected version of the 3300 XL 8mm Probes.
