Bently Nevada – 330141-08-90-01-05 Proximity Probes With Armor

Description

Overview

The Bently Nevada 330141 8 mm Probe (Product No. 330141-08-90-01-05) is engineered for extreme industrial environments requiring extended reach and explosion-proof compliance. Featuring a 9.0-meter armored cable and ClickLoc connector with protector, it ensures secure, long-distance connectivity in corrosive or high-vibration settings.

Technical Specifications

• Brand: Bently Nevada
• Model: 330141 3300 XL 8 mm Probe (Armored)
• 330141-08-90-01-05 Suffix Code Breakdown:
  • 08: 0.8-inch armored case length
  • 90: 9.0-meter cable (29.5 feet)
  • 01: ClickLoc connector with protector (standard cable)
  • 05: CSA, ATEX, IECEx certifications
• DC Resistance:
  • Value: 9.87 Ω ±0.50 (9.0m cable)
• Incremental Scale Factor (ISF):
  • Standard (5m): 7.87 V/mm ±5% (200 mV/mil)
  • Extended (9m): 7.87 V/mm ±6.5%
• Deviation from Straight Line (DSL):
  • Standard: < ±0.025 mm (±1 mil)
  • Extended: < ±0.038 mm (±1.5 mil)
• Materials:
  • Tip: Polyphenylene sulfide (PPS)
  • Case: AISI 304 stainless steel

Contact Support

For certification documents or custom configurations:
sales@ubestplc.com

Explore more detailed information in official datasheet here: 3300 XL 8 mm Proximity Transducer System Datasheet
