Bently Nevada 330185-01 Calibration Micrometer for 3300 XL Vibration Transducers

Description

Introducing the Bently Nevada 330185-01 Precision Micrometer

This is the 3300 XL Precision Micrometer 330185-01. It is the ideal tool for acceptance testing and performance verification of vibration transducer systems. Ensure your machinery protection systems meet strict specifications, including API 670 standards. This tool guarantees your monitoring equipment provides accurate and reliable data.

Complete Technical Specifications

• Brand: Bently Nevada
• Model: 3300 XL Precision Micrometer
  • Part Number Suffix: 330185-01
    • -01: Indicates micrometer scale in English units (0-1 inch).
• Core Measurement Parameters:
  • Measurement Range: 0 to 1 inch.
  • Resolution: 0.000020 in.
  • Accuracy: ± 0.000015 in.
  • Linearity: Verified against system DSL (Deviation from Straight Line) tolerances.
• Mechanical Construction:
  • Target Button: High-precision AISI 4140 alloy steel, 30.5 mm diameter.
  • Casing Material: Durable fiberglass and plastic composite.
• Environmental & General:
  • Temperature Range: Designed for ambient and extended temperature specification testing.
  • Dimensions (Case): 356 mm L x 274 mm W x 226 mm H.
  • Weight: 6.8 kg.

Key Applications & Diagnostic Power

• Perform acceptance tests on new Bently Nevada transducer systems.
• Verify the Average Scale Factor (ASF) and Incremental Scale Factor (ISF).
• Check system performance against published linearity and tolerance specifications.
• Validate the proper operation of shaft position monitoring channels.
• Ensure compliance with industry standards like API 670.

Installation, Compatibility & Support

• Installation Guide: The probe mounts securely into a dedicated adapter on the tool.
• Setup & Maintenance: The process is straightforward. Generate a probe curve and compare it to specifications. The robust design requires minimal maintenance.
• Compatibility Note: Primarily designed for Bently Nevada 3300 XL and compatible proximity transducer systems. Contact us for special target material requests.
• Certification: Manufactured to meet Bently Nevada’s precision specifications for calibration.
• Packaging: The unit arrives New & Original in Factory Packing.
• Warranty: Backed by a 12-month factory warranty.
• Shipping: We ship worldwide via FedEx, UPS, and DHL.

Frequently Asked Questions (FAQ)

• What does the -01 suffix in the part number mean?
• The -01 suffix specifies that the micrometer’s integrated scale reads in English units (inches), with a 0-1 inch range.
• Can I use this to calibrate transducers from other manufacturers?
• It is optimized for Bently Nevada systems. You can use it for others if their specification verification method is similar, but results should be compared to the respective manufacturer’s specs.
• What equipment do I need besides the micrometer?
• You need a compatible proximity probe, a Proximitor power supply/monitor, and a precise voltmeter to record the output voltage.
• From experience, can this tool check a transducer on a running machine?
• No. The 3300 XL Micrometer is for static, bench-top calibration. It simulates shaft motion under controlled conditions to verify the transducer’s intrinsic electrical performance.
• How often should I verify my transducer systems with this tool?
• We recommend verification during initial installation (acceptance), after any maintenance on the monitoring system, and periodically as part of a preventive maintenance schedule.
