Description
Product Overview
The Bently Nevada 330185-02 is a high-precision micrometer. It is essential for verifying the performance of transducer monitoring systems. This tool ensures your machinery protection systems meet strict specifications, including API 670 standards. It is supplied new and original in factory sealed packaging.
Key Technical Data
Complete specifications for the 3300 XL Precision Micrometer.
- Brand: Bently Nevada
- Model & Part Number: 330185-02
- Series: 3300 XL Precision Micrometer
- Suffix Detail: -02 indicates metric scale (0-25 mm)
- Measurement Range: 0 to 25 mm
- Resolution: 0.0005 mm
- Accuracy: ± 0.0004 mm
- Linearity: High precision, conforms to API 670
- Sensitivity: Optimized for transducer verification
- Frequency Response: For static and slow dynamic testing
- Temperature Range: Suitable for standard industrial ambient conditions
- Environmental Durability: Robust casing for shop floor use
- Interference Immunity: Stable output in industrial electrical environments
- Target Button: AISI 4140 Alloy Steel, 30.5 mm diameter
- Casing Material: Fiberglass and Plastic composite
- Unit Dimensions (H x W x L): 226 mm x 274 mm x 356 mm
- Unit Weight: 6.8 kg (14.5 lb)
Installation Guide
- Secure the probe in the dedicated mounting adapter.
- Align the high-precision target button with the probe tip.
- Connect the Proximitor sensor output to a precision voltmeter.
- Ensure a stable, vibration-free base for accurate measurements.
Setup & Maintenance Convenience
- Simple calibration via micrometer’s fine-threaded spindle.
- Minimal maintenance required; keep target surface clean.
- Sturdy construction ensures long-term reliability.
Compatibility Notes
- Designed for testing Bently Nevada 3300 XL and compatible transducer systems.
- Ideal for verifying systems to API 670 (Machinery Protection Systems) standard.
- Consult factory for special target material requirements.
Certifications & Warranty
- Manufactured to meet published performance specifications.
- Supports compliance verification for industry standards.
- Full Factory Warranty: 12 Months from date of purchase.
Packaging List & Shipping
- Includes 3300 XL Precision Micrometer unit and target button.
- All components are new in original factory packing.
- Fast worldwide shipping via FedEx, UPS, or DHL available.
Diagnostic Capabilities
- Generates precise probe calibration curves for comparison.
- Verifies system operation within ambient and extended temperature tolerances.
- Helps identify transducer system degradation or fault conditions.
Frequently Asked Questions (FAQ)
What is the primary purpose of this tool?
It verifies the accuracy and health of vibration and position transducer systems.
Can I use it to check my existing monitor’s health?
Yes, it is perfect for verifying the input side of shaft position monitors.
Technical Specifications
What does the ‘-02’ in the part number mean?
It specifies the micrometer scale is in metric units (0-25 mm).
Is the target button replaceable for different applications?
The standard button is AISI 4140 steel. Contact us for special material options.
Usage & Best Practices
What is a common mistake during calibration?
Moving the target too quickly. Use small, precise increments for stable readings.
How can I ensure my test results are valid?
Always use a calibrated voltmeter and allow system warm-up time as per manual.
